The EDT SX14Q004 is a 14.0-inch a-Si TFT-LCD module designed for applications requiring large, high-quality displays with excellent visual clarity. With a resolution of 1280x768 (WXGA) and a pixel density of 102 PPI, this module ensures sharp, crisp visuals and accurate color reproduction, making it suitable for a range of industries including industrial, medical, and commercial electronics.

With a brightness of 500 cd/m² and a contrast ratio of 800:1, the EDT SX14Q004 provides high-contrast images that are visible even in brightly lit environments. The wide viewing angles of 85°/85°/85°/85° (L/R/U/D) ensure the display remains clear from various angles, making it ideal for applications that require multiple viewing positions.

The module also features an LED backlight, offering energy efficiency and a long operational lifespan. The antiglare surface treatment reduces reflections and enhances readability, ensuring the display performs well in a variety of lighting conditions.

Key Features:

• Brand: EDT
• Model: SX14Q004
• Diagonal Size: 14.0 inches
• Resolution: 1280×768 (WXGA), 102 PPI
• Pixel Format: RGB Vertical Stripe for vibrant and accurate color reproduction
• Active Area: 304.128(W) × 190.944(H) mm
• Bezel Opening: 307.2(W) × 193.2(H) mm
• Outline Dimensions: 325(W) × 206(H) × 7.3(D) mm
• Surface Treatment: Antiglare to enhance readability in bright environments
• Brightness: 500 cd/m² (Typical), ensuring clear visibility in bright settings
• Contrast Ratio: 800:1 (Typical), providing rich, high-contrast images
• Viewing Angle: 85°/85°/85°/85° (L/R/U/D), offering clarity from various angles
• Backlight Type: LED, for energy-efficient operation and long lifespan
• Display Mode: TN, Normally White, Transmissive
• Response Time: 25 ms (Typical, Tr/Td) for smooth and responsive visuals
• Signal Interface: LVDS (1 channel, 6-bit), 40-pin FPC connector
• Input Voltage: 3.3V (Typical for VCC)
• Operating Temperature: -20°C to 70°C, designed for use in a variety of environments
• Storage Temperature: -30°C to 80°C, suitable for flexible storage conditions

Applications:

• Industrial Control Panels: Ideal for industrial systems requiring a clear, large display
• Point-of-Sale (POS) Displays: Perfect for retail systems needing vibrant and reliable displays
• Medical Devices: Suitable for medical equipment requiring clear and accurate visuals
• Consumer Electronics: A great choice for consumer devices where display size and quality matter

Technical Precautions:

• Handling: Handle carefully to avoid damage to the display or internal components
• ESD Protection: Use electrostatic discharge (ESD) precautions during installation
• Temperature Limits: Ensure the module operates within the recommended temperature range (-20°C to 70°C) for optimal performance
• Installation Guidelines: Avoid excessive pressure on connectors to maintain long-term reliability
• Backlight Maintenance: Regularly inspect the backlight to ensure continued performance
