EDT SX14Q006 LCD Module

EDT SX14Q006 LCD Module

The EDT SX14Q006 is a 14.0-inch a-Si TFT-LCD module designed for high-performance applications requiring vibrant, sharp displays. With a resolution of 1280x768 (WXGA) and a pixel density of 102 PPI, this module provides crisp, clear visuals with accurate color reproduction, making it suitable for a variety of industrial, commercial, and consumer electronics applications.

The brightness of 500 cd/m² and a contrast ratio of 800:1 ensure that this module delivers vivid, high-contrast images, even in bright or well-lit environments. The wide viewing angles of 85°/85°/85°/85° (L/R/U/D) guarantee consistent image clarity from various perspectives, making it ideal for applications requiring multi-angle viewing.

The module features an LED backlight for energy-efficient operation and a long operational lifespan, while the antiglare surface treatment improves readability by reducing reflections, ensuring visibility even in bright conditions.

Key Features:

• Brand: EDT
• Model: SX14Q006
• Diagonal Size: 14.0 inches
• Resolution: 1280×768 (WXGA), 102 PPI
• Pixel Format: RGB Vertical Stripe for accurate and vibrant color reproduction
• Active Area: 304.128(W) × 190.944(H) mm
• Bezel Opening: 307.2(W) × 193.2(H) mm
• Outline Dimensions: 325(W) × 206(H) × 7.3(D) mm
• Surface Treatment: Antiglare for improved readability in bright environments
• Brightness: 500 cd/m² (Typical), ideal for use in environments with high ambient light
• Contrast Ratio: 800:1 (Typical), ensuring vivid and distinct images
• Viewing Angle: 85°/85°/85°/85° (L/R/U/D), for clear viewing from multiple angles
• Backlight Type: LED for energy-efficient performance and long lifespan
• Display Mode: TN, Normally White, Transmissive
• Response Time: 25 ms (Typical, Tr/Td) for smooth and responsive visuals
• Signal Interface: LVDS (1 channel, 6-bit), 40-pin FPC connector
• Input Voltage: 3.3V (Typical for VCC)
• Operating Temperature: -20°C to 70°C, suitable for a variety of operating conditions
• Storage Temperature: -30°C to 80°C, allowing flexible storage options

Applications:

• Industrial Control Panels: Suitable for use in industrial settings where large, clear, and high-contrast displays are essential
• Point-of-Sale (POS) Displays: Ideal for retail environments requiring clear visuals for customer interaction
• Medical Equipment: Perfect for medical devices that require vibrant and precise image clarity
• Consumer Electronics: Great for consumer devices where display size and quality are key

Technical Precautions:

• Handling: Handle carefully to prevent damage to the surface or internal components
• ESD Protection: Use electrostatic discharge (ESD) precautions during installation
• Temperature Limits: Ensure the module operates within the recommended temperature range (-20°C to 70°C) for optimal performance
• Installation Guidelines: Avoid applying excessive pressure on connectors during installation for long-term reliability
• Backlight Maintenance: Regularly inspect the backlight to ensure continued performance
