Tianma TM104SDH01 LCD Module

Tianma TM104SDH01 LCD Module

The Tianma TM104SDH01 is a 10.4-inch a-Si TFT-LCD module designed for applications requiring high-quality, reliable displays in industrial and commercial settings. This display offers a resolution of 800x600 (SVGA) and a pixel density of 96 PPI, delivering clear visuals with good color accuracy. The RGB Vertical Stripe pixel arrangement ensures vibrant and consistent color reproduction, making it ideal for devices that demand high visual performance.

With a brightness of 500 cd/m² and a contrast ratio of 600:1, this module is suitable for use in bright environments where visibility is essential. The wide viewing angles of 85°/85°/85°/85° (L/R/U/D) allow for consistent image clarity from multiple directions, making it versatile for various applications.

The module also features an LED backlight with a 50,000-hour lifespan, ensuring long-term reliability. Additionally, its antiglare surface treatment enhances readability and reduces reflections, making it ideal for environments with ambient light.

Key Features:

• Brand: Tianma
• Model: TM104SDH01
• Diagonal Size: 10.4 inches
• Resolution: 800×600 (SVGA), 96 PPI
• Pixel Format: RGB Vertical Stripe for accurate and vibrant color reproduction
• Active Area: 211.2(W) × 158.4(H) mm
• Bezel Opening: 214.4(W) × 161.6(H) mm
• Outline Dimensions: 245.0(W) × 188.0(H) × 12.5(D) mm
• Surface Treatment: Antiglare for enhanced readability in bright environments
• Brightness: 500 cd/m² (Typical), ideal for use in bright settings
• Contrast Ratio: 600:1 (Typical), ensuring high-quality visuals with sharp differentiation
• Viewing Angle: 85°/85°/85°/85° (L/R/U/D), offering clear viewing from various angles
• Backlight Type: LED with a 50,000-hour lifespan for extended use
• Display Mode: TN, Normally White, Transmissive
• Response Time: 30 ms (Typical, Tr/Td) for smooth, responsive visuals
• Signal Interface: LVDS (1 channel, 6/8-bit), 40-pin FPC connector
• Input Voltage: 3.3V (Typical for VCC)
• Operating Temperature: -20°C to 70°C, designed to operate in a variety of conditions
• Storage Temperature: -30°C to 80°C, suitable for flexible storage in varying environments

Applications:

• Industrial Control Panels: Ideal for industrial systems where space is limited but high-quality displays are necessary
• Point-of-Sale (POS) Displays: Suitable for retail systems that require vibrant colors and compact, reliable displays
• Medical Devices: Perfect for small medical equipment where clarity and precision are crucial
• Embedded Systems: Suitable for embedded applications requiring a reliable display for data visualization

Technical Precautions:

• Handling: Handle carefully to avoid damage to the surface or internal components
• ESD Protection: Use electrostatic discharge (ESD) precautions during installation to protect the module
• Temperature Limits: Ensure the module operates within the recommended temperature range (-20°C to 70°C) for optimal longevity
• Installation Guidelines: Avoid excessive pressure on connectors during installation to maintain reliability
• Backlight Maintenance: Regularly inspect the backlight, which has a 50,000-hour lifespan, to ensure continued performance
