NTS TG19264A LCD Module

NTS TG19264A LCD Module

The NTS TG19264A is a 2.0-inch a-Si TFT-LCD module designed to offer compact, high-quality display performance for applications requiring small form factor displays. Featuring a resolution of 192x64, this module provides clear and crisp visuals with a pixel density of 96 PPI, making it suitable for industrial control panels, POS systems, embedded devices, and other applications that require a reliable, small display.

This module has a brightness of 300 cd/m² and a contrast ratio of 500:1, ensuring excellent visibility and image clarity, even in environments with ambient light. The wide viewing angles of 60°/60°/50°/60° (L/R/U/D) provide consistent image quality from various angles, making it versatile for different types of usage.

The TG19264A comes equipped with an LED backlight, which enhances energy efficiency and ensures a long lifespan. The antiglare surface treatment reduces reflections, making it perfect for use in bright or outdoor environments where clear readability is crucial.

Key Features:

• Brand: NTS
• Model: TG19264A
• Diagonal Size: 2.0 inches
• Resolution: 192×64, 96 PPI
• Pixel Format: RGB Vertical Stripe for accurate and vibrant color reproduction
• Active Area: 38.4(W) × 12.8(H) mm
• Bezel Opening: 41.0(W) × 15.0(H) mm
• Outline Dimensions: 46.0(W) × 19.0(H) × 5.0(D) mm
• Surface Treatment: Antiglare for better visibility and readability
• Brightness: 300 cd/m² (Typical), ensuring clear visuals in various lighting conditions
• Contrast Ratio: 500:1 (Typical), providing vibrant and clear images
• Viewing Angle: 60°/60°/50°/60° (L/R/U/D), allowing consistent image clarity from multiple angles
• Backlight Type: LED for energy-efficient performance and extended lifespan
• Display Mode: TN, Normally White, Transmissive
• Response Time: 25 ms (Typical, Tr/Td) for smooth visual transitions
• Signal Interface: RGB 6-bit, 40-pin FPC connector
• Input Voltage: 3.3V (Typical for VCC)
• Operating Temperature: -20°C to 70°C, suitable for use in various environmental conditions
• Storage Temperature: -30°C to 80°C, flexible for different storage environments

Applications:

• Industrial Control Panels: Ideal for compact industrial displays where space is limited but high-quality visuals are needed
• Point-of-Sale (POS) Displays: Suitable for retail systems that require small, clear displays with vibrant colors
• Embedded Systems: Perfect for small devices or systems requiring reliable, efficient display solutions
• Medical Devices: Ideal for diagnostic equipment or small medical tools where clarity is essential

Technical Precautions:

• Handling: Handle with care to avoid damaging the surface or internal components
• ESD Protection: Use electrostatic discharge (ESD) precautions during installation
• Temperature Limits: Ensure the module operates within the recommended temperature range (-20°C to 70°C) for optimal performance
• Installation Guidelines: Avoid excessive pressure on connectors during installation to maintain reliability
• Backlight Maintenance: Regularly inspect the backlight to ensure consistent performance
