Innolux G104S1-L01 LCD Module

Innolux G104S1-L01 LCD Module

The Innolux G104S1-L01 is a 10.4-inch a-Si TFT-LCD module designed for applications that require high-quality displays with exceptional visual clarity. Featuring a resolution of 1024x768 (XGA) and a pixel density of 98 PPI, this module delivers clear and sharp visuals, making it ideal for industrial, medical, and commercial applications that require a larger display.

With a brightness of 400 cd/m² and a contrast ratio of 500:1, the G104S1-L01 ensures clear, easy-to-read images in environments with varying light conditions. The wide viewing angles of 80°/80°/80°/80° (L/R/U/D) offer consistent image clarity from multiple directions, making this display versatile for applications requiring multiple viewing positions.

The module is equipped with a LED backlight, providing long-lasting performance and energy efficiency, making it suitable for extended use in demanding environments. The antiglare surface treatment reduces reflections and enhances readability, ensuring a high-quality visual experience in bright and ambient lighting conditions.

Key Features:

• Brand: Innolux
• Model: G104S1-L01
• Diagonal Size: 10.4 inches
• Resolution: 1024×768 (XGA), 98 PPI
• Pixel Format: RGB Vertical Stripe for vibrant and accurate color reproduction
• Active Area: 211.2(W) × 158.4(H) mm
• Bezel Opening: 213.2(W) × 160.4(H) mm
• Outline Dimensions: 239.0(W) × 178.8(H) × 7.5(D) mm
• Surface Treatment: Antiglare for reduced reflections and improved visibility
• Brightness: 400 cd/m² (Typical), suitable for environments with moderate ambient light
• Contrast Ratio: 500:1 (Typical), ensuring clear differentiation between light and dark areas
• Viewing Angle: 80°/80°/80°/80° (L/R/U/D), delivering consistent image clarity from different angles
• Backlight Type: LED for energy efficiency and long lifespan
• Display Mode: TN, Normally White, Transmissive
• Response Time: 25 ms (Typical, Tr/Td) for smooth, responsive visuals
• Signal Interface: LVDS (1 channel, 6/8-bit), 30-pin FPC connector
• Input Voltage: 3.3V (Typical for VCC)
• Operating Temperature: -20°C to 70°C, designed for a wide range of operating environments
• Storage Temperature: -30°C to 80°C, flexible storage conditions

Applications:

• Industrial Control Panels: Ideal for use in industrial systems where a medium-sized, high-quality display is essential
• Medical Devices: Suitable for medical devices and diagnostic equipment that require large, clear displays
• Point-of-Sale (POS) Displays: Perfect for retail systems that need an easy-to-read, vibrant display
• Portable Devices: Great for handheld devices requiring a larger, clear screen

Technical Precautions:

• Handling: Handle with care to avoid damaging the surface or internal components
• ESD Protection: Use electrostatic discharge (ESD) precautions during installation to protect the module
• Temperature Limits: Ensure the module operates within the recommended temperature range (-20°C to 70°C) for optimal performance
• Installation Guidelines: Avoid excessive pressure on connectors during installation to maintain long-term reliability
• Backlight Maintenance: Regularly inspect the backlight to ensure consistent performance
