The Hitachi SP14Q006 is a 14.0-inch a-Si TFT-LCD module designed for high-performance applications that require a large display with precise visuals. With a resolution of 1280x768 (WXGA) and a pixel density of 102 PPI, this module delivers sharp and clear visuals with accurate color reproduction, making it an excellent choice for industrial, commercial, and consumer electronics applications.

The brightness of 500 cd/m² and a contrast ratio of 800:1 ensure vibrant and high-contrast images, even in bright environments. With wide viewing angles of 85°/85°/85°/85° (L/R/U/D), the module maintains consistent image clarity from various perspectives, making it ideal for applications that require a high-quality display from multiple viewing angles.

Equipped with an LED backlight, the module provides energy-efficient performance and a long lifespan. The antiglare surface treatment enhances readability and reduces reflections, ensuring optimal visibility, even in bright or high-light environments.

Key Features:

• Brand: Hitachi
• Model: SP14Q006
• Diagonal Size: 14.0 inches
• Resolution: 1280×768 (WXGA), 102 PPI
• Pixel Format: RGB Vertical Stripe for clear, vibrant color reproduction
• Active Area: 304.128(W) × 190.944(H) mm
• Bezel Opening: 307.2(W) × 193.2(H) mm
• Outline Dimensions: 325(W) × 206(H) × 7.3(D) mm
• Surface Treatment: Antiglare for enhanced readability in bright environments
• Brightness: 500 cd/m² (Typical), ideal for bright environments
• Contrast Ratio: 800:1 (Typical), providing vivid images with clear differentiation
• Viewing Angle: 85°/85°/85°/85° (L/R/U/D), ensuring consistent image quality from multiple angles
• Backlight Type: LED for energy-efficient performance and long operational lifespan
• Display Mode: TN, Normally White, Transmissive
• Response Time: 25 ms (Typical, Tr/Td) for smooth and responsive visuals
• Signal Interface: LVDS (1 channel, 6-bit), 40-pin FPC connector
• Input Voltage: 3.3V (Typical for VCC)
• Operating Temperature: -20°C to 70°C, for reliable performance in varying conditions
• Storage Temperature: -30°C to 80°C, suitable for flexible storage

Applications:

• Industrial Control Panels: Perfect for large industrial systems requiring clear and vibrant displays
• Point-of-Sale (POS) Displays: Ideal for retail systems that require large, high-contrast displays for customer interaction
• Medical Equipment: Suitable for medical devices and diagnostic tools that require large, clear, and vibrant visuals
• Consumer Electronics: Great for consumer devices where screen size and clarity are essential

Technical Precautions:

• Handling: Handle carefully to prevent damage to the surface or internal components
• ESD Protection: Use electrostatic discharge (ESD) precautions during installation to protect the module
• Temperature Limits: Operate within the recommended temperature range (-20°C to 70°C) for optimal performance
• Installation Guidelines: Avoid excessive pressure on connectors to ensure long-term reliability
• Backlight Maintenance: Regularly check the backlight to ensure continued performance
