Sharp LQ084V1DG21 LCD Module

Sharp LQ084V1DG21 LCD Module

The Sharp LQ084V1DG21 is an 8.4-inch a-Si TFT-LCD display module designed for industrial and professional use. Featuring a SVGA resolution (800x600), this display provides sharp image quality with vibrant colors, ideal for various embedded systems and monitoring applications. It is designed with an antiglare surface to improve visibility in bright environments, ensuring consistent performance in various lighting conditions.

The module uses an LED backlight for improved energy efficiency and a long lifespan, ensuring reliable operation in diverse settings. The display is ideal for industrial control systems, medical devices, and other applications where a compact, high-performance display is required.

Key Features:

• Brand: Sharp
• Model: LQ084V1DG21
• Diagonal Size: 8.4 inches
• Resolution: 800×600 (SVGA), 100 PPI
• Pixel Format: RGB Vertical Stripe for accurate and sharp color reproduction
• Active Area: 170.4(W) × 127.8(H) mm
• Bezel Opening: 173.4(W) × 131.4(H) mm
• Outline Dimensions: 198.6(W) × 151.5(H) × 11.0(D) mm
• Surface Treatment: Antiglare for reduced reflections and improved visibility in bright environments
• Brightness: 350 cd/m² (Typical), ensuring clear visibility in varied lighting
• Contrast Ratio: 500:1 (Typical), providing deep blacks and bright whites for clear image clarity
• Viewing Angle: 60°/60°/50°/70° (Left/Right/Up/Down), providing good visibility from different angles
• Display Mode: Normally White, Transmissive, offering consistent and vibrant visuals
• Response Time: 25 ms (Typical), for smooth image transitions with reduced motion blur
• Backlight Type: LED, with a long lifespan of up to 50,000 hours, offering energy-efficient performance
• Signal Interface: LVDS (1 channel, 6/8-bit), 20-pin Connector for reliable data transmission
• Input Voltage: 3.3V (Typical)
• Operating Temperature: 0°C to 50°C, ideal for indoor industrial applications
• Storage Temperature: -20°C to 60°C, allowing for safe storage in diverse conditions

Applications:

• Industrial Control Systems: Suitable for use in manufacturing systems, machine interfaces, and control panels
• Medical Equipment: Ideal for medical diagnostic and monitoring displays
• Embedded Systems: Perfect for small embedded applications requiring reliable and clear visual output
• Point-of-Sale Systems: Used in kiosks, terminals, and digital signage for commercial displays

Technical Precautions:

• Handling: Handle carefully to prevent damage to the display surface and internal components
• Electrostatic Safety: Ensure ESD (Electrostatic Discharge) precautions are followed during installation and maintenance
• Temperature Compliance: Operate within the recommended temperature range (0°C to 50°C) for optimal performance
• Connection Guidelines: Power down the module before making any connections to avoid electrical damage
• Mounting Recommendations: Use manufacturer-approved fixtures for secure installation, especially in industrial environments
