Leuze FT5.3/2N Diffuse Sensor

Leuze FT5.3/2N Diffuse Sensor

The Leuze FT5.3/2N Diffuse Sensor  is a compact and reliable energetic diffuse sensor designed for precise object detection in short-range industrial applications. Utilizing a 620 nm red LED, this sensor operates on the diffuse reflection principle, making it ideal for detecting a wide variety of surfaces with varying reflectivity—from bright white to dark black materials.

It offers a guaranteed operating range up to 215 mm for high-reflectivity surfaces (90% white), with detection capability down to 125 mm for dark objects (6% black). Its response time of 1 ms and switching frequency of 500 Hz ensure effective performance in moderately fast automation environments.

Housed in a durable ABS plastic body, the FT5.3/2N features a 4-wire cable connection, IP67 protection, and LED indicators for clear operational feedback. Its compact footprint (14 x 32.5 x 20.2 mm) and Teach button simplify setup and installation, even in tight spaces.

With both NPN light and dark switching outputs, the sensor provides flexible integration options across a wide range of machines and conveyors in manufacturing and packaging lines.

Key features :-

Applications :-

• Short-Range Object Detection
  Ideal for detecting objects of varying reflectivity at close range in packaging, assembly, and robotics.
• Compact Automation Systems
  Its small form factor allows easy integration into tight mounting spaces or compact machines.
• Light & Dark Switching
  Equipped with both light and dark switching via NPN output, suitable for different detection scenarios.
• Moist or Dusty Environments
  With an IP67-rated housing and robust PUR cable, it's built for durability in harsh conditions.
• Quick Installation and Tuning
  Teach button functionality simplifies sensor calibration for fast deployment and adjustments on the floor.

Precautions:

• Ensure Correct Wiring: Incorrect connections can cause sensor failure
• Avoid Overvoltage: Operating within 10-30V DC prevents damage
• Protect from Extreme Heat: Avoid installing near high-temperature sources
• Regular Cleaning: Keep the optical lens free from dust and debris for optimal performance
