Sharp LQ104V1DG81 LCD Module

Sharp LQ104V1DG81 LCD Module

The Sharp LQ104V1DG81 is a 10.4-inch a-Si TFT-LCD module designed for high-performance applications that require a compact, reliable display solution. With a resolution of 800x600 (SVGA) and a pixel density of 96 PPI, this module offers clear and sharp visuals with good color reproduction, making it ideal for industrial, medical, and commercial applications.

This module features a brightness of 400 cd/m² and a contrast ratio of 500:1, ensuring good visibility in a range of lighting conditions. The wide viewing angles of 80°/80°/80°/80° (L/R/U/D) provide consistent image clarity from various positions, enhancing its usability across different settings.

Equipped with an LED backlight, the display offers an extended lifespan, contributing to long-term durability and energy efficiency. The antiglare surface treatment reduces reflections and improves readability, making it ideal for use in environments with ambient light.

Key Features:

• Brand: Sharp
• Model: LQ104V1DG81
• Diagonal Size: 10.4 inches
• Resolution: 800×600 (SVGA), 96 PPI
• Pixel Format: RGB Vertical Stripe for accurate and vibrant color reproduction
• Active Area: 211.2(W) × 158.4(H) mm
• Bezel Opening: 214.2(W) × 161.4(H) mm
• Outline Dimensions: 246.0(W) × 185.0(H) × 10.8(D) mm
• Surface Treatment: Antiglare for enhanced readability in bright environments
• Brightness: 400 cd/m² (Typical), suitable for various lighting conditions
• Contrast Ratio: 500:1 (Typical), ensuring clear and vivid images
• Viewing Angle: 80°/80°/80°/80° (L/R/U/D), providing consistent image clarity from multiple viewing angles
• Backlight Type: LED with an extended lifespan for long-term reliability
• Display Mode: TN, Normally White, Transmissive
• Response Time: 20 ms (Typical, Tr/Td) for smooth and responsive visuals
• Signal Interface: LVDS (1 channel, 6/8-bit), 30-pin FPC connector
• Input Voltage: 3.3V (Typical for VCC)
• Operating Temperature: 0°C to 50°C, designed for use in various operating environments
• Storage Temperature: -20°C to 60°C, suitable for flexible storage conditions

Applications:

• Industrial Control Panels: Ideal for industrial settings requiring compact, high-quality displays
• Medical Devices: Suitable for medical equipment needing high clarity and precision
• Point-of-Sale (POS) Displays: Perfect for retail systems demanding vibrant color and clear readability
• Embedded Systems: Suitable for embedded applications where display size and clarity are important

Technical Precautions:

• Handling: Handle carefully to avoid damage to the surface or internal components
• ESD Protection: Use electrostatic discharge (ESD) precautions during installation to protect the module
• Temperature Limits: Ensure the module operates within the recommended temperature range (0°C to 50°C) for optimal performance
• Installation Guidelines: Avoid excessive pressure on connectors during installation to maintain long-term reliability
• Backlight Maintenance: Regularly inspect the backlight to ensure continued performance
