Leuze PRK5B.M1/4 Photoelectric Sensor
Leuze PRK5B.M1/4 Photoelectric Sensor
Leuze PRK5B.M1/4 Photoelectric Sensor
Leuze PRK5B.M1/4 Photoelectric Sensor
Leuze PRK5B.M1/4 Photoelectric Sensor
Leuze PRK5B.M1/4 Photoelectric Sensor
Leuze PRK5B.M1/4 Photoelectric Sensor
Leuze PRK5B.M1/4 Photoelectric Sensor
Leuze

Leuze PRK5B.M1/4 Photoelectric Sensor

Product SKU: NTSSEN00666
Available:
Only 25 items in stock
25 items in stock
In stock
Pre-order
Out of stock
  • Brand:  Leuze
  • Part No.: 50149298
  • Switching frequency: 500 Hz
  • Voltage supply range: 10 V DC ... 30 V DC
  • Connection types: Cable
  • Housing material: Plastic

Note : All tax and custom duty should be pay by buyer only.

For Indian Buyers: IndustryShoppy.in

$185.00
$300.00
Notify me When Available
You will receive an email when the product is available.
Want it delivered by
  • Description
  • Specifications
  • Declaration

Leuze PRK5B.M1/4 Photoelectric Sensor

The Leuze PRK5B.M1/4 Photoelectric Sensor 5B Series Retro-Reflective Sensor (Part No. 50145252) is a compact reflection-type sensor engineered for reliable detection of bottle containers, transparent films, and semi-transparent materials.

Using a red LED light source (645 nm) with a reflector, it delivers a guaranteed sensing range up to 4.5 m and a typical range up to 6 m, ensuring stable performance in packaging and bottling lines. The sensor features a PNP transistor output with light switching, a fast 1 ms response time, and a 500 Hz switching frequency for dependable operation in dynamic processes.

Operating on 10–30 V DC, it includes a 270° potentiometer for precise sensitivity adjustment. The IP67-rated PC-ABS housing, ECOLAB material compatibility, and wide –40 to +60 °C operating temperature make it suitable for demanding industrial and washdown environments.




Applications

  • Detection of bottle containers on packaging lines

  • Detection of transparent films and semi-transparent media

  • Use in conveyor and material handling systems

  • Suitable for food, beverage, and pharmaceutical automation


Technical Precautions

• Ensure correct alignment with the reflector for stable detection

• Avoid strong ambient or direct light on the sensing area

• Use only within the specified 10–30 V DC supply range

• Keep sensor lens and reflector clean for consistent performance


While our engineers carefully upload product details based on official datasheets, occasional errors may still occur. We encourage users to verify specifications as needed for complete accuracy.

IndustryShoppy.com offers a wide selection of industrial automation products—from sensors and HMIs to PLCs and more. Designed for convenience, our platform ensures a smooth shopping experience backed by reliable service and customer-focused support. Explore our extensive range and elevate your industrial operations with confidence.

Note : All tax and custom duty should be pay by buyer only.

Note: All trademarks and trade names used are the property of their respective owners.


Facebook, YouTube,


ModelPRK5B.M1/4
BrandLEUZE
Part No.50149298
Series5B
Operating principalReflection principle
ApplicationsDetection of bottle containers; semi-transparent media; transparent films
Operating range (guaranteed)0.03 … 4.5 m (with reflector TK(S) 100 × 100)
Operating range limit (typical)0.03 … 6 m (with reflector TK(S) 100 × 100)
Light sourceLED, red
Wavelength645 nm
Transmitted-signal shapePulsed
LED groupExempt group (according to EN 62471)
Supply voltage UB10 … 30 V DC (including residual ripple)
Residual ripple0 … 15 % from UB
Open-circuit current0 … 20 mA
Output typeDigital switching output
Switching elementTransistor, PNP
Switching principleLight switching
Switching frequency500 Hz
Response time1 ms
Readiness delay300 ms
FunctionSignal OUT, voltage supply
Type of connectionCable
Cable length2,000 mm
Sheathing materialPVC
Cable colorBlack
Number of conductors3-wire
Wire cross section0.14 mm²
Dimensions (W × H × L)11 × 32.4 × 20 mm
Housing materialPlastic
Plastic housingPC-ABS
Lens cover materialPlastic
Housing colorBlack / Red
Type of fasteningTwo M3 threaded sleeves; optional mounting device
Recommended tightening torque (M3)0.9 N·m
Material compatibilityECOLAB
Display typeLED
Number of LEDs2
Operational controls270° potentiometer
Control functionSensitivity adjustment
Ambient temperature (operation)–40 … +60 °C
Ambient temperature (storage)–40 … +70 °C
Degree of protectionIP67
Protection classIII
Approvalsc UL US
Standards appliedIEC 60947-5-2
Country of originMalaysia
