The Kyocera KCG057QV1DB-G77 LCD Module is a compact 5.7-inch QVGA (320x240) display designed for applications that require a clear and bright output. It features 380 cd/m² luminance, ensuring readability even in moderately lit environments. Its 60:1 contrast ratio allows for clear text and image differentiation, making it suitable for various industrial and embedded systems.

With 55/55/60/75-degree viewing angles, this module provides excellent visibility from different perspectives, ensuring users can view the screen comfortably from multiple angles. The CSTN-LCD technology offers improved color reproduction, supporting a wide range of colors in STN, Normally Black, Transmissive mode.

The display operates at a 75Hz frame rate and is powered by 3.3/5.0V, making it energy-efficient and easy to integrate into various systems. It utilizes a CCFL backlight, which provides a long lifespan of up to 75,000 hours, ensuring durability for long-term use in industrial settings.

Key features :-

• Brand: Kyocera
• Model: KCG057QV1DB-G77
• Diagonal Size: 5.7"
• Resolution: 320×240, QVGA, 70 PPI
• Active Area: 115.2(W)×86.4(H) mm
• Outline Dimension: 144(W)×104.8(H)×13.2(D) mm
• Luminance: 380 cd/m² (Typical)
• Contrast Ratio: 60:1 (Typical) (TM)
• Viewing Angle: 55/55/60/75 (Typical) (CR≥2)
• Response Time: 450 ms (Typical) (Tr+Td)
• Panel Type: CSTN-LCD, LCM
• Operating Mode: STN, Normally Black, Transmissive
• Support Color: Color
• Signal Interface Type: Parallel Data (1ch, 8-bit), 20 pins Connector
• Frame Rate: 75Hz
• Power Supply: 3.3/5.0V (Typical) (VDD)
• Backlight: CCFL, 75K hours, No Driver
• Operating Temperature: Not Provided
• Storage Temperature: Not Provided

Applications:

• Industrial Control Systems Ideal for factory automation displays.
• Medical Devices Clear readouts for diagnostic equipment.
• Embedded Devices Versatile for integration into small form factor systems.
• Test Instruments Efficient and stable display for test measurements.
• Consumer Electronics Suitable for small displays in handheld devices.

Technical Precautions:

• Handling Care: Handle carefully to protect the hard-coated surface from damage
• Connection Instructions: Always power off the display before connecting
• Temperature Limits: Maintain operating temperatures between -10°C to 50°C for optimal performance
• Mounting Guidelines: Use appropriate fittings for secure installation, especially in industrial settings
• Backlight Maintenance: Ensure regular inspections as the backlight has a lifespan of 20,000 hours
