Delta TP02G-AS1 HMI Panel

Delta TP02G-AS1 HMI Panel

The Delta TP02G-AS1 HMI Panel is a smart and space-saving operator interface, designed to provide clear, simple data display and reliable interaction with industrial machines. It features a monochromatic STN LCD screen with a 160x32 resolution to present machine data and operator menus crisply.

Equipped with function and numeric keys (F0–F9, ESC, ENTER, ARROW), the panel ensures efficient navigation and user input even in demanding environments. The LED backlight supports automatic turn-off for energy conservation and longer display life.

Communication is smooth and reliable thanks to RS-232 and RS-485 ports, allowing easy integration into existing systems. With a 24V DC power supply and 256K memory, this HMI panel balances simplicity and durability for process monitoring.

Its IP65/NEMA4-rated front panel protects against water and dust, while its natural air cooling design ensures reliable, long-term use in industrial conditions.

Key features :-

Applications :-

• Parameter Display: Shows key machine data in real time for operators.
• User Control: Simplifies interaction using intuitive function and numeric keys.
• Alarm Notification: Alerts users to real-time machine status and errors.
• System Communication: Supports smooth data exchange via RS-232/RS-485 ports.
• Compact Installation: Fits in small panels with IP65-rated durability.

Precautions:

• Power Supply: Use a stable 24VDC source with proper grounding to prevent damage.
• Installation Environment: Avoid exposure to direct sunlight, excessive dust, or corrosive gases.
• Temperature & Humidity: Operate only within the specified 0°C–45°C temperature and 5%–90% humidity range.
• Wiring: Ensure all communication and power cables are properly shielded to avoid interference.
• Maintenance: Disconnect power before cleaning or performing any hardware adjustments.

Note : All tax and custom duty should be pay by buyer only.

Note: All trademarks and trade names used are the property of their respective owners.
