Baumer OR18.ZI-11206600 Diffuse Sensor

Baumer OR18.ZI-11206600 Diffuse Sensor

Part No. 11206600

The Baumer OR18.ZI-11206600 Diffuse Sensor is engineered for precision object detection using intensity difference technology. With a sensing distance of 10 to 600 mm, this sensor delivers fast, accurate detection supported by a pulsed infrared diode operating at 880 nm. It features a complementary PNP output for both light and dark operation modes, making it adaptable to varying application needs.

Equipped with short-circuit and reverse polarity protection, it ensures durability in demanding environments. The response time is under 0.5 ms, allowing real-time performance in automated systems. The 270° potentiometer enables easy sensitivity adjustment, while LED indicators provide clear status feedback for power and target detection.

Built with a nickel-plated brass cylindrical housing, this sensor is IP67 rated for moisture and dust resistance. It includes a 4-pin cable connection and operates reliably in temperatures from -25°C to +55°C. With low power consumption and suppression of reciprocal influence, it’s ideal for use in tightly spaced sensor arrays and complex industrial settings.

Key features :-

Applications :-

• Automated Packaging Lines: Ensures presence detection of products for consistent packing operations.
• Robotic Handling: Enhances object recognition and positioning in robotic arms for industrial tasks.
• Conveyor Belt Systems: Monitors item flow and prevents errors in high-speed material transport systems.
• Assembly Stations: Supports part detection and placement accuracy in automated assembly lines.
• Bottling and Labeling Machines: Identifies object presence and triggers mechanisms in fast-paced production lines.

Precautions:

• Ensure Correct Wiring: Incorrect connections can cause sensor failure
• Avoid Overvoltage: Operating within 10-30V DC prevents damage
• Protect from Extreme Heat: Avoid installing near high-temperature sources
• Regular Cleaning: Keep the optical lens free from dust and debris for optimal performance
