Datalogic IS-12-C1-S2 Inductive Sensor

Datalogic IS-12-C1-S2 Inductive Sensor

The Datalogic IS-12-C1-S2 Inductive Proximity Sensor (Product Number: IS-12-C1-S2, Part Number: 95B061651) offers robust and reliable non-contact metal detection, designed for industrial automation environments requiring compact, durable, and high-precision sensing. This M12 no-flush mount sensor provides a nominal sensing distance of 4 mm, with an operational range of 0–3.24 mm, making it ideal for close-proximity object detection.

Equipped with a PNP Normally Open output, the IS-12-C1-S2 supports fast switching speeds up to 1 kHz and a 0.5 ms response time, ensuring quick feedback in high-speed applications. The nickel-plated brass housing offers mechanical strength and IP67 protection, while features like short-circuit protection, reverse polarity protection, and resistance to inductive loads ensure safety and longevity in demanding environments. It also includes clear yellow LED status indication, an M12 connector, and support for standard metal targets with various correction factors.

This sensor is CE, cULus, ECOLAB, and DIVERSEY approved, making it a versatile and certified solution for a range of industrial sensing needs.

Key features :-

Applications :-

• Automated Machinery: Accurately detects metal parts in moving equipment without contact or wear.
• Packaging Lines: Ensures proper placement or presence of metallic components in fast-paced lines.
• Material Handling: Detects object positioning or limits in conveyors and mechanical guides.
• Robotics: Used for end-of-arm tooling to confirm presence of metal parts during assembly.
• Food & Beverage Industry: Suitable for washdown environments, thanks to IP67 and ECOLAB approvals.
• Automotive Production: Monitors alignment and presence of metal objects with high switching frequency.

Precautions:

• Ensure Correct Wiring: Incorrect connections can cause sensor failure
• Avoid Overvoltage: Operating within 10-30V DC prevents damage
• Protect from Extreme Heat: Avoid installing near high-temperature sources
• Regular Cleaning: Keep the optical lens free from dust and debris for optimal performance
