Delta DVP08SM11N PLC Module

Delta DVP08SM11N PLC Module

The Delta DVP08SM11N PLC Module is a highly reliable and efficient digital input extension unit, designed to enhance industrial control systems with smooth and stable performance. It operates on a 24VDC power supply, ensuring steady functionality even in challenging environments.

This model offers 8 digital input channels, expanding your system's capabilities with seamless integration and compatibility. The program capacity of 30k steps allows for flexible and complex automation logic, making it ideal for diverse industrial setups.

Built to endure harsh working conditions, the DVP08SM11N boasts superior spike voltage durability and insulation impedance, ensuring safety and performance stability. Its ESD, EFT, and RF immunity meet international standards, guaranteeing smooth operations even amid electrical noise and interference.

Designed with practicality in mind, the module's compact form factor and 10ms response time support efficient real-time control. Whether you're expanding an existing system or developing new automation solutions, the Delta DVP08SM11N offers both reliability and efficiency for modern industrial needs.

Key features :-

• Brand: Delta
• Series: DVP
• Model No.: DVP08SM11N
• Power Supply: 24VDC (-15%~20%)
• Number of Inputs and Type: Digital - 8
• Number of Outputs and Type: Not Applicable
• Fuse Capacity: ES: 2A/250VAC; SV: 2.5A/30VDC
• Power Consumption: 1W
• Program Capacity: 30k Steps
• Spike Voltage Durability: 1500VAC (Primary-secondary); 1500VAC (Primary-PE); 500VAC (Secondary-PE)
• Insulation Impedance: >5 MΩ (all I/O points to ground: 500VDC)
• Noise Immunity: ESD: 8kV Air; EFT: Power Line 2kV, Digital I/O 1kV, Analog & Comm I/O 1kV; RS: 26 MHz~1GHz, 10V/m
• Earth: Grounding wire must be no thinner than power supply cable; each PLC must be grounded properly when used in multiples
• Storage / Operation Temperature: Storage: -25ºC ~ 70ºC; Operation: 0ºC ~ 55ºC
• Storage / Operation Humidity: Storage: -25ºC ~ 70ºC; Operation: 0ºC ~ 55ºC
• Response Time: 10ms
• Vibration / Shock Resistance: IEC1131-2, IEC 68-2-6 (TEST Fc); IEC1131-2 & IEC 68-2-27 (TEST Ea)
• Input Signal Voltage: 24VDC ±10% (5 mA)

Applications :-

• Factory Automation: Integrates easily into conveyor, sorting, and packaging control systems.
• Process Control: Enhances data input reliability in chemical, food, and beverage plants.
• Building Automation: Supports lighting, HVAC, and security system integrations.
• Machine Automation: Ideal for CNC, cutting, and assembly line input monitoring.
• Energy Management: Facilitates efficient input data logging in power distribution panels.

Technical Precautions :-

• Ensure all connections are secure, especially for RS-232 and RS-485 communication ports, to maintain reliable data transmission.
• Maintain a stable 24V DC power supply to optimize module performance and prevent malfunctions.
• Avoid installation in high-vibration or extremely humid environments to protect the hardware.
• Always follow the proper wiring diagram when connecting additional modules to avoid overloading the system.
• Proper grounding is essential to avoid damage due to electromagnetic interference (EMI).
