Delta DOP-107BV HMI Operator Panel
Delta DOP-107BV HMI Operator Panel
Delta

Delta DOP-107BV HMI Panel

Product SKU: NTSHMI00010
Available:
Only 2 items in stock
2 items in stock
In stock
Pre-order
Out of stock
$165.00
$300.00
Notify me When Available
You will receive an email when the product is available.
Want it delivered by
  • Description
  • Declaration

Delta DOP-107BV HMI Panel

The Delta DOP-107BV HMI Panel is built for seamless machine interaction and intuitive process visualization. Equipped with a 7-inch TFT LCD and 800x480 resolution, this panel delivers vibrant and crisp displays under demanding industrial conditions.

Its ARM Cortex-A8 processor (800MHz) combined with 256MB Flash ROM and RAM ensures fast, reliable performance for critical applications. The 4-wire resistive touchscreen offers over 1 million operation cycles, ideal for heavy usage environments.

Designed for flexibility, the panel supports USB Host & Slave interfaces, as well as RS-232, RS-422, and RS-485 communication for broad system compatibility. Backed by CE, UL, IP65, and NEMA4 (indoor) certifications, the DOP-107BV ensures safe and dependable operation.

The compact size and natural air circulation cooling make this unit easy to integrate into various control systems, while its durable structure ensures longevity even in vibration-prone setups.

Key features :-

Model DOP-107BV
Display Panel type 7″ TFT LCD (65535 colors)
Resolution 800 x 480 pixels
Backlight LED backlight (half-life under room temperature 25oC > 20,000 hours)*1
Display range 154.08 mm * 85.92 mm
Brightness 400 cd / m² (Typ.)
CPU ARM Cortex-A8 (800 MHz)
Flash ROM 256 Mbytes
RAM 256 Mbytes
Touchscreen 4-wire resistive touchscreen > 1,000,000 operated
Buzzer Multi-tone frequency (2 K – 4 KHz) / 80 dB
Network interface N/A
USB 1 USB Slave Ver 2.0; 1 USB Host Ver 2.0
SD N/A
Serial communication port COM1 RS-232 (supporting flow control) / RS-485*2
COM2 RS-422 / RS-485*2
COM3 N/A
Auxiliary function key N/A
Calendar Built-in
Cooling method Natural cooling
Approvals CE / UL (please use shielding network cable and magnetic ring with the filter of 300 ohm / 100 MHz)
Panel waterproof level IP65 / NEMA4 / UL TYPE 4X (indoor use only)
Operation voltage*2 DC +24V (-15% to +15%) (please use an isolated power supply) Supplied by Class 2 or SELV circuit (isolated from MAINS by double insulation)
Leakage current 500 VAC for 1 minute (between DC24V terminal and FG terminal)
Power consumption*2 8.6 W (Max)*3
Backup battery 3V lithium battery CR2032 × 1
Backup battery life About 3 years or more at 25oC
(subject to operation temperature and condition)
Operation temperature 0oC to 50oC (32oF to 122oF)
Storage temperature -20oC to +60oC (-4oF to 140oF)
Operating environment 10% – 90% RH [0oC – 40oC], 10% – 55% RH [41oC – 50oC];
pollution degree: 2
Vibration resistance Conforms to IEC61131-2: continuous vibration 5 Hz – 8.3 Hz with amplitude 3.5 mm; 8.3 Hz – 150 Hz with amplitude 1G
Shock resistance Conforms to IEC60068-2-27:
11 ms, 15 G Peak, in X, Y, Z directions each for 6 times
Dimension 215 x 161 x 35.5
(W) x (H) x (D) mm
Mounting dimension 196.9 x 142.9
(W) x (H) mm



Applications :-

  • Factory Automation: Streamlines monitoring and control for production lines.
  • System Diagnostics: Offers real-time system status and error alerts.
  • Machine Interface: Simplifies operator interaction and settings adjustment.
  • Remote Monitoring: Ensures reliable data visualization via serial ports.
  • Energy Management: Displays power usage and operational efficiency feedback.

Precautions:

  • Power Supply: Use a stable 24VDC source with proper grounding to prevent damage.
  • Installation Environment: Avoid exposure to direct sunlight, excessive dust, or corrosive gases.
  • Temperature & Humidity: Operate only within the specified 0°C–45°C temperature and 5%–90% humidity range.
  • Wiring: Ensure all communication and power cables are properly shielded to avoid interference.
  • Maintenance: Disconnect power before cleaning or performing any hardware adjustments.

Note : All tax and custom duty should be pay by buyer only.

Note: All trademarks and trade names used are the property of their respective owners

Note : All tax and custom duty should be pay by buyer only.

Note: All trademarks and trade names used are the property of their respective owners.

Accuracy Disclaimer: Specifications provided are based on datasheet and are subject to change without notice. While every effort has been made to ensure accuracy, errors may occur. Users are encouraged to verify specifications with the manufacturer and consult for any specific questions or requirements.
