Wenglor WM03PCT2S614 Color Mark Sensor

Wenglor WM03PCT2S614 Color Mark Sensor

The Wenglor WM03PCT2S614 color sensor delivers exceptional color recognition performance in industrial environments, thanks to its high-resolution detection and rapid response time. Designed with a working distance of 15 mm and an adjustable working range from 12 to 18 mm, it features a light spot diameter of just 1.5 × 2.5 mm, enabling precise detection of subtle color differences on small or fast-moving targets.

Powered by a white light source spanning 400 to 700 nm, this sensor achieves accurate color resolution with a gray scale resolution of 20. With a switching frequency of 10 kHz and an ultra-fast response time of 50 µs, the sensor supports high-speed production lines. PNP NO/NC outputs, combined with short-circuit, overload, and reverse polarity protection, ensure safe and flexible integration.

The Wenglor WM03PCT2S614 color sensor supports Teach-In settings via ZT and FT modes, allowing easy configuration. Its IP67-rated housing, plastic enclosure, and operating range from -25°C to +60°C make it robust for harsh environments. With a 100,000-hour light source lifespan, it offers long-term reliability for demanding applications.

Key features :-

• Color Mark Detection: Ideal for detecting color marks on packaging materials, labels, and products, ensuring proper identification and alignment in packaging systems.
• Sorting Systems: Used in sorting and classification systems where items are sorted based on color, such as in the textile, automotive, and food industries.
• Automated Production Lines: Integrated into automated production lines to detect and differentiate between colored products or labels, ensuring correct placement or routing.
• Quality Control: Applied in quality control systems to ensure proper color coding, checking for correct color placement, and identifying defects.
• Labeling and Packaging: Frequently used in labeling and packaging lines to ensure accurate color identification and alignment of products, preventing errors during production.
• Assembly Line Monitoring: Used for monitoring color-coded components during assembly, ensuring accurate placement and verification during automated assembly processes.

Precautions:

• Ensure Correct Wiring: Incorrect connections can cause sensor failure
• Avoid Overvoltage: Operating within 10-30V DC prevents damage
• Protect from Extreme Heat: Avoid installing near high-temperature sources
• Regular Cleaning: Keep the optical lens free from dust and debris for optimal performance
