Datalogic S50-PA-5-C21-PP Photoelectric Sensor

Datalogic S50-PA-5-C21-PP Photoelectric Sensor

S50-PA-5-C21-PP is no obsolete new model : S5N-PA-5-C21-PP

The Datalogic S50-PA-5-C21-PP Photoelectric Sensor (952002180) is a reliable and compact solution for industrial object detection within an operating distance of 0 to 40 cm. It uses an infrared LED light source (880 nm) to ensure stable and accurate sensing across various applications.

Designed for flexibility, the sensor features a sensitivity trimmer for fine adjustment and supports PNP outputs with NO and NC modes, allowing easy integration into control systems. With a fast response time of 0.5 ms and a switching frequency of 1 kHz, it performs efficiently in high-speed automation processes.

Clear LED indicators provide instant feedback on output and stability status. Built with a rugged PBT housing, PMMA lens, and IP67 protection, the S50 sensor delivers dependable performance even in harsh industrial environments while complying with EN 60947-5-2 standards.

Applications:

• Object detection on conveyors and automated material handling systems.

• Position sensing in packaging, labeling, and bottling machines.

• Presence detection of parts in assembly and production lines.

• Smart factory integration using IO-Link–enabled automation networks.



Technical Precautions:

• Use only the specified 10–30 VDC supply voltage.

• Avoid excessive ambient light beyond recommended limits.

• Ensure proper alignment and secure mounting to prevent false detection.

• Follow correct wiring and grounding to reduce electrical interference.
