Panasonic EX-L221 Laser Sensor

Panasonic EX-L221 Laser Sensor

The Panasonic EX-L221 Laser Sensor (Part Number: UEXL221) is a high-precision optical sensor designed for reliable distance measurement in a variety of industrial applications. With a sensing range of 45 to 300 mm (1.772 to 11.811 in), the EX-L221 can detect small objects as tiny as ø1 mm (0.039 in), ensuring accurate and efficient detection even for fine details. This makes it suitable for applications requiring highly precise measurements and small object detection.

Equipped with a red semiconductor laser (Class 1) and an emission spot size of ø1 mm at 300 mm, the EX-L221 offers exceptional accuracy and focus. The PNP open-collector transistor output is configurable for Light-ON or Dark-ON operation, providing flexible integration with various control systems. The sensor is also equipped with short-circuit protection and inverse polarity protection, ensuring robust operation in industrial environments.

The Panasonic EX-L221 Laser Sensor comes with a sensitivity adjuster for fine-tuning, a fast response time of 0.5 ms, and is built to meet IP67 protection standards, making it resistant to dust and water. Designed to operate in ambient temperatures from -10°C to +55°C and under harsh environmental conditions, the Panasonic EX-L221 Laser Sensor is an ideal choice for precision detection in diverse industries.

Key features :-

Applications :-

• Automated Manufacturing: Detects small components in high-speed production processes, enhancing precision and efficiency.
• Quality Control: Ensures accurate inspection and measurement of parts to prevent defects in products.
• Packaging: Monitors the position and alignment of items in high-speed packaging lines.
• Material Handling: Ideal for detecting objects on conveyor belts or in sorting systems.
• Robotics: Provides critical object detection feedback for robotic arms in assembly, sorting, and inspection tasks.

Precautions :-

• Ensure Correct Wiring: Incorrect connections can cause sensor failure
• Avoid Overvoltage: Operating within 10-30V DC prevents damage
• Protect from Extreme Heat: Avoid installing near high-temperature sources
• Regular Cleaning: Keep the optical lens free from dust and debris for optimal performance

Note : All tax and custom duty should be pay by buyer only.

Note: All trademarks and trade names used are the property of their respective owners.
