Panasonic EX-32A Photoelectric Sensor

Panasonic EX-32A Photoelectric Sensor

The Panasonic EX-32A is a miniature threaded photoelectric sensor designed for reliable diffuse reflective detection in tight industrial spaces. With a sensing range of 50 mm, it accurately detects opaque, translucent, or transparent objects—even in challenging environments.

This sensor features an NPN open-collector output (max 50 mA), a fast 0.5 ms response time, and integrated short-circuit protection for safe operation. It includes LED indicators—orange for output and green for stability—ensuring easy status monitoring during use.

The EX-32A runs on 12–24 V DC and maintains low power consumption (13 mA max). Users can fine-tune performance using its continuously variable sensitivity adjuster, while the die-cast zinc housing (nickel-plated) with acrylic lens ensures durability under harsh industrial conditions. It’s rated IP67, making it suitable for washdown or dusty environments.

The unit comes with a 2-meter cable, is CE and UL certified, and tolerates high shock and vibration, making it ideal for demanding automation setups. Lightweight at just 20 g, it offers high performance in a compact, rugged form factor.

Key features :-

Applications :-

• Assembly Line Object Detection: Ideal for short-range sensing of small components on compact and high-speed production lines, ensuring precise detection and placement.
• Label and Packaging Inspection: Suitable for detecting transparent, glossy, or colored materials such as plastic films, glass bottles, or printed labels in packaging systems.
• Small-Part Sorting Machines: Perfect for use in rapid sorting systems where accuracy and compact sensor size are essential for detecting fast-moving items.
• Robotic End-Effectors: Lightweight and threaded for easy mounting on robotic arms, allowing accurate object presence detection during automated picking or placement.
• Electronics Manufacturing: Well-suited for detecting tiny, delicate electronic parts on PCBs or trays, helping ensure process accuracy in confined assembly areas.

Precautions:

• Ensure Correct Wiring: Incorrect connections can cause sensor failure
• Avoid Overvoltage: Operating within 10-30V DC prevents damage
• Protect from Extreme Heat: Avoid installing near high-temperature sources
• Regular Cleaning: Keep the optical lens free from dust and debris for optimal performance

Note : All tax and custom duty should be pay by buyer only.

Note: All trademarks and trade names used are the property of their respective owners.
