Leuze GS63B/6D.3 Photoelectric Sensor

Leuze GS63B/6D.3 Photoelectric Sensor

Part No. 50146327

The Leuze GS63B/6D.3 Photoelectric Sensor is a precision-engineered solution for detecting non-transparent labels with outstanding reliability and speed. Designed with a robust fork-style housing and a 3 mm mouth width, it ensures stable and accurate detection even at high conveyor speeds.

This sensor uses a pulsed infrared LED (940 nm) for sharp signal separation and reliable sensing of minimum 2 mm label gaps. The push-pull transistor output enables flexible integration into various control systems, while the fast 0.05 ms response time makes it ideal for high-speed labeling and packaging lines.

The GS63B/6D.3 is built for durability with a chemically nickel-plated diecast zinc body combined with resilient PC plastic components, providing excellent mechanical strength and an IP67 protection rating. Integrated polarity reversal and short-circuit protection ensure safe and stable operation in challenging industrial environments.

With simple setup via the teach-in button and visual feedback through three clear LED indicators, this sensor is easy to install and configure. It’s the perfect choice for precise label detection in conveyor systems, print-and-apply, packaging, and product tracking applications.

Key features :-

Applications :-

• Label Detection: Reliable detection of non-transparent labels in automated systems.
• Packaging Lines: Ensure labels are present for quality control.
• Print-and-Apply Systems: Detect label gaps to trigger print commands.
• Conveyor Speed Verification: High-speed detection up to 20 m/min during teach-in.
• Product Identification: Confirm label placement in sorting and tracking setups.

Precautions:

• Ensure Correct Wiring: Incorrect connections can cause sensor failure
• Avoid Overvoltage: Operating within 10-30V DC prevents damage
• Protect from Extreme Heat: Avoid installing near high-temperature sources
• Regular Cleaning: Keep the optical lens free from dust and debris for optimal performance
