Leuze ET28.3/4P-M12 Diffuse Sensor

Leuze ET28.3/4P-M12 Diffuse Sensor

The Leuze ET28.3/4P-M12 Diffuse Sensor is engineered for accurate and reliable detection using the diffuse reflection principle. Designed to identify objects across varied surfaces, it offers a guaranteed operating range of up to 0.65 meters and an extended range limit reaching 0.85 meters on white reflective targets.

Equipped with PNP transistor outputs and supporting both light and dark switching, the sensor adapts effortlessly to various machine control systems. Its 620 nm red LED light source ensures consistent and stable performance, even in applications involving challenging surface finishes or color contrasts.

The robust ABS plastic housing with an IP67 rating ensures resistance to dust, water, and harsh industrial environments. A reliable M12 4-pin male connector simplifies electrical integration, while LED status indicators offer intuitive feedback during setup and operation.

Whether you’re automating material handling, verifying object presence, or enhancing production line safety, this sensor’s 1ms response time and flexible configuration deliver dependable results.

Key features :-

Applications :-

• Object Detection: Identifies items on production lines with reliable background suppression.
• Position Sensing: Accurately detects object placement in automated machinery.
• Conveyor Monitoring: Ensures smooth flow and presence detection in logistics systems.
• Packaging Lines: Detects product presence for correct filling or sealing operations.
• Assembly Automation: Confirms part positions to maintain process consistency.

Precautions:

• Ensure Correct Wiring: Incorrect connections can cause sensor failure
• Avoid Overvoltage: Operating within 10-30V DC prevents damage
• Protect from Extreme Heat: Avoid installing near high-temperature sources
• Regular Cleaning: Keep the optical lens free from dust and debris for optimal performance
