Panasonic NA1-PK3 Photoelectric Sensor

The Panasonic NA1-PK3 area sensor is engineered for dependable and precise detection of opaque objects in industrial environments. With a sensing height of 49.2 mm and a sensing range from 30 to 300 mm, it ensures consistent performance for various applications. The device features three beam channels and a beam pitch of 24.6 mm, offering robust coverage with a minimum detectable object size of ø29 mm.

Equipped with NPN open-collector transistor outputs, this sensor supports flexible integration and includes short-circuit protection for operational safety. It supports both ON and OFF output modes, selectable via an onboard mode switch. Designed for industrial reliability, it meets EMC and RoHS directives, and boasts IP62 protection, making it resistant to dust and water splashes.

Operational stability is enhanced with interference prevention (up to three units close-mounted) and clear LED indicators for power, job, and beam reception. Built to withstand harsh environments, it operates between -10°C to +55°C and resists vibration and shock. The infrared LED emitter and rugged ABS housing ensure long-lasting performance in demanding settings.

Key features :-

Product Number NA1-PK5
Part Number UNA1PK5
Item Performance characteristics
CE Marking Directive Compliance EMC Directive, RoHS Directive
Sensing Height 100 mm 3.937 in
Sensing Range 0.1 to 1.2 m 0.328 to 3.937 ft
(0.05 to 0.5 m 0.164 to 1.640 ft when set to SHORT)(Note) The sensing range is the possible setting distance between the emitter and the receiver.
Beam Pitch 25 mm 0.984 in
Number of Beam Channels 5 beam channels
Sensing Object ø35 mm ø1.378 in or more opaque object
(completely beam interrupted object)
Supply Voltage 12 to 24 V DC plus or minus 10 % Ripple P-P 10 % or less
Power Consumption Emitter: 0.5 W or less
Receiver: 0.8 W or less
(Note) Obtain the current consumption by the following equation.
Current consumption = Power consumption / Supply voltage
(e.g.) When the supply voltage is 12 V, the current consumption of the emitter is
0.5 W / 12 V ≈ 0.042 A = 42 mA
Output NPN open-collector transistor
- Maximum sink current: 100 mA
- Applied voltage: 30 V DC or less (between output and 0 V)
- Residual voltage: 1 V or less (at 100 mA sink current), 0.4 V or less (at 16 mA sink current)
Output: Utilization Category DC-12 or DC-13
Output: Output Operation ON or OFF when one or more beam channels are interrupted / ON or OFF when two or more beam channels are interrupted, selectable by operation mode switch
Output: Short-Circuit Protection Incorporated
Response Time 10 ms or less (when the interference prevention is used, in Light state: 30 ms or less, in Dark state: 13 ms or less)
Indicators: Emitter Power indicator: Green LED (lights up when the power is ON)
Job indicator: Orange LED (lights up or blinks when the job indicator input is Low, lighting pattern is selected by operation mode switch)
Indicators: Receiver Operation indicator: Red LED (lights up when one or more beam channels are interrupted, but lights up when two beam channels or more are interrupted in the double-beam interruption mode)
Stable incident beam indicator: Green LED (lights up when all beam channels are stably received)
Job indicator: Orange LED (lights up or blinks when the job indicator input is Low, lighting pattern is selected by operation mode switch)
Interference Prevention Function Incorporated
Pollution Degree 3 (Industrial environment)
Protection IP62 (IEC)
Ambient Temperature -10 to +55 ℃ +14 to +131 ℉
(No dew condensation or icing allowed),
Storage: -20 to +70 ℃ -4 to +158 ℉
Ambient Humidity 35 to 85 % RH, Storage: 35 to 85 % RH
Ambient Illuminance Incandescent light: 3,000 lx or less at the light-receiving face
Voltage Withstand ability 1,000 V AC for one min. between all supply terminals connected together and enclosure
Insulation Resistance 20 MOhm , or more, with 250 V DC megger between all supply terminals connected together and enclosure
Vibration Resistance 10 to 150 Hz frequency, 0.75 mm 0.030 in double amplitude in X, Y and Z directions for two hours each
Shock Resistance 490 m/s2 acceleration (50 G approx.) in X, Y and Z directions three times each
Emitting Element Infrared LED
(Peak emission wavelength: 950 nm 0.037 mil, synchronized scanning system)
Material Enclosure: Heat-resistant ABS
Lens cover: Acrylic
Indicator cover: Acrylic
Cable 0.3 mm2 4-core (emitter: 3-core) oil resistant cabtyre cable, 2 m 6.562 ft long
Cable Extension Extension up to total 100 m 328.084 ft is possible for both emitter and receiver with 0.3 mm2, or more, cable.



Applications :-

  • Industrial Automation: Reliable object detection on assembly lines using synchronized scanning.
  • Packaging Lines: Ideal for confirming package presence or alignment in compact conveyors.
  • Material Handling: Detects passing boxes or pallets without physical contact.
  • Electronics Manufacturing: Supports automated placement and verification processes.
  • Quality Control: Ensures object presence or absence in machine vision or rejection systems.

Precautions :-

  • Ensure Correct Wiring: Incorrect connections can cause sensor failure
  • Avoid Overvoltage: Operating within 10-30V DC prevents damage
  • Protect from Extreme Heat: Avoid installing near high-temperature sources
  • Regular Cleaning: Keep the optical lens free from dust and debris for optimal performance
